Digital Printer For Fabric

Digital Printer For Fabric

1. The bottom wheel of the printing machine. When cleaning the table glue on the table, avoid the table glue sticking to the bottom wheel. If necessary, wipe off the glue with a dry cloth, otherwise it will directly affect the accuracy of printing. 2. The air source processor on the digital...
Send Inquiry
Product Introduction

Digital printers for fabric are a modern and innovative way to print high-quality designs onto fabrics. These printers are designed to efficiently and accurately transfer digital images or designs onto a wide range of fabrics for various applications. They are commonly used in industries such as fashion and interior design, where creating unique designs on fabrics is essential.



The specifications of typically include features like high-resolution printing, fast printing speed, and compatibility with a variety of fabric types. These printers also have variable drop size technology, allowing them to print fine details and gradients with accuracy and precision. Other features may include automatic fabric feeding, dye-sublimation printing, and rechargeable ink systems.



are commonly used for applications such as printing graphics onto t-shirts, decorating curtains, or creating personalized bedding. These printers are also used in the production of custom clothing, allowing fashion designers to create unique pieces with vibrant, eye-catching designs.











Product mode

YSR1816

Print head

8pcs Ricoh Gen6 print head

Fabric conveyance mode

Adhesive belt with cleaning and heating system

Maximum medium width

1850mm

Production speed

Gen5 E

2 pass:330m2/h

Print software

Neostampa / Texprint

Ink Type

reactive , disperse or acid ink,pigment(8 color)

Power voltage

380V,3L+N+G(with independent reliable effective earth wire)

Power consumption

printer 15kw, electric dyer 20kw(steam dryer 4kw)

Workshop condition

Temperature:20-30℃,humidity:55-65%

Measurement(with wooden case)

Printer

4700*2200*1950mm (L* W* H)

Dryer

2300*2200*1950mm (L* W* H)

Weight

G.W:4800kg N.W.:4200KG







product-1032-619

product-1032-594



product-560-334

1. The bottom wheel of the printing machine. When cleaning the table glue on the table, avoid the table glue sticking to the bottom wheel. If necessary, wipe off the glue with a dry cloth, otherwise it will directly affect the accuracy of printing.



2. The air source processor on the digital printing machine needs to close the air and drain twice a day; the aerosol oil should be adjusted to 4-5 drops per minute, and the air must be closed when refueling.



3. Emergency stop switch, during use, the emergency stop switch on the printing machine should be used as little as possible, so as not to affect the life of the chain, drag chain, and timing belt.



4. The joint head can drip butter (one week/time, 10-20g), engine oil (1-2 drops, 3 days/time).
